Product Description
Square D QO 50A Double-Pole Circuit Breaker is designed for use in Square D QO load centers. Its primary function is to provide overload and short-circuit protection for electrical systems, enhancing the safety and reliability of the electrical distribution. Certification and Rating: ANSI (American National Standards Institute) is certified and UL (Underwriter's Laboratories) is listed, ensuring compliance with industry standards and safety requirements. The breaker is rated for both 120 volts and 240 volts and has an interrupting rating (AIR - Ampere Interrupting Rating) of 10,000 AIR, which means it can safely interrupt the current flow during a fault. Visi-Trip Indicator: The circuit breaker is equipped with an exclusive Visi-Trip indicator. When the breaker trips due to an overload or short circuit, the handle snaps to a midpoint position, and an obvious red indicator appears. This indicator provides a clear visual signal, making it easy to identify which breaker has tripped for quick troubleshooting and reset.
Model Number: QO250CP
Specifications
- Amperage: 50
- Voltage: 120/240
- Number of Poles: 2-Pole
- Mount Type: Plug-In
- Wire Size: #8-2 AWG
- Certification: ANSI/UL Listed
- Interruption Type: Standard Trip
- Frame Size: 2-Space
- Breaker Size: 3/4 In.
