Product Description
Innovation Cooksmart® feature - 4 preset frying levels controlled by a sensor Performance Five elements and ten cooking zones provides the space and power for most cookware Large triple element offers the capability to use multiple pan sizes Residual heat indicator shows you what elements are still hot Wipe protection function allows user to clean the surface of the control panel without risk of changing the settings Design Touch control panel with blue light illumination offers 17 power settings Full stainless steel frame
Features
- Masterpiece® Series electric cooktops offer excellent performance, precise control and a sleek elegant profile
- Illuminated Touch Control Panel : this intuitive panel allows for simple selection of power levels and easy cleaning, while being seamlessly integrated into your cooktop.
- Stainless Steel Frame : A sleek frame surrounds the cooktop surface.
- CookSmart® : A sensor ensures optimal results with 4 preset frying levels, each programmed for different types of food.
- Dual Zone Bridge Element : is an exclusive feature that connects two round cooking zones, enabling use of large oval or rectangular cookware for even heating.
- Triple Element : Combine three cooking zones into one to adapt to the size of your cookware.
Specifications
| Dimension of 3rd heating element (mm) | 120 ; 180 |
|---|
| Number of induction elements | 0 |
|---|
| Net weight (kg) | 15.6 |
|---|
| Power on indicator | Yes |
|---|
| Number of electric cooking zones | 5 |
|---|
| Overall appliance dimensions (HxWxD) | 7/16"+4 " x 37" x 21 1/4" |
|---|
| Frequency (Hz) | 60 |
|---|
| Product packaging dimensions (HxWxD) | 8 1/4" x 43 5/16" x 24" |
|---|
| Dimension of 3rd heating element | 5" ; 7" |
|---|
| Type of control | Electronic |
|---|
| Ignition system | No |
|---|
| Minimum width for installation (mm) | 883 |
|---|
| Location of 2nd heating element | center left |
|---|
| Type of control | Front |
|---|
| Total number of cooktop burners | 5 |
|---|
| Additional Image 4 | https |
|---|
| Energy input | Electric |
|---|
| Power of the heating element | 1.7 |
|---|
| Gross weight | 44.000 |
|---|
| Type of frame | Convenience frame |
|---|
| Additional Image 1 | https |
|---|
| Number of halogen elements | 0 |
|---|
| Product group | Hob |
|---|
| Minimum distance from counter front | 2 1/4 |
|---|
| Current (A) | 50/40 |
|---|
| Power cord length (cm) | 96.0 |
|---|
| Minimum height for installation (mm) | 505 |
|---|
| Number of electric elements | 0 |
|---|
| Net weight | 34.000 |
|---|
| Plug type | No Plug |
|---|
| UPC code | 825225960249 |
|---|
| EAN code | 825225960249 |
|---|
| Dimension of 5th heating element (mm) | 140 |
|---|
| Gross weight (kg) | 19.8 |
|---|
| Automatic programmes | Yes |
|---|
| Additional Image 2 | https |
|---|
| Product name / series name | Cooking zone ceramic |
|---|
| Type of 3rd heating element | Radiant heating |
|---|
| Height of the packed product (mm) | 210 |
|---|
| Location of the heating element | front left |
|---|
| Timer | Yes |
|---|
| Location of 6th heating element | center right |
|---|
| Number of radiant elements | 5 |
|---|
| Number of gas burners | 0 |
|---|
| Additional Image 3 | https |
|---|
| Location of 3rd heating element | back left |
|---|
| Color of frame | Stainless Steel |
|---|
| Included accessories | 1 x glass scraper |
|---|
| Depth for installation (mm) | 100 |
|---|
| Basic surface material | Ceramic |
|---|
| Burners with booster | Front right |
|---|
| Minimum distance from rear wall | 2 |
|---|
| Power of 3rd heating element (kW) | 0.7 ; 1.7 |
|---|
| Location of 5th heating element | back right |
|---|
| Maximum width for installation (mm) | 886 |
|---|
| Brand | Thermador |
|---|
| Dimension of 1st heating element | 7" |
|---|
| Depth of the packed product (mm) | 1100 |
|---|
| Type of lid | Without |
|---|
| Highlights | 17 power levels, fryingSensor Plus |
|---|
| Construction type | Built-in |
|---|
| Safety device | Auto Safety Shutoff;Childproof Lock;Panel Lock |
|---|
| Additional Image 5 | https |
|---|
| dishwasher safe pan support | No |
|---|
| Dimension of the heating element | 180 |
|---|
| Sealed Burners | No |
|---|
| Maximum height for installation (mm) | 508 |
|---|
| Internal article number | CET366YB |
|---|
| Type of 5th heating element | Radiant heating |
|---|
| Number of electric warming zones | 0 |
|---|
| Type of regulation | Stepless energy regulated |
|---|
| Dimension of 5th heating element | 6" |
|---|
| Main on/off switch | Yes |
|---|
| Type of heating element | Radiant heating |
|---|
| Required cutout size (HxWxD) | 4 " x 34 3/4 " x 19 7/8 " |
|---|
| Volts (V) | 240/208 |
|---|
| Location of 4th heating element | middle back |
|---|
| Power of 5th heating element (kW) | 1.2 |
|---|
| SKU | CET366YB |
|---|
| Width of the packed product (mm) | 610 |
|---|
| Plate on indicator | 1 |
|---|
| Location of control panel | Front |
|---|
