| Height to Top of Rear Vent Trim | 37.375 in |
|---|
| Cooktop Type | Standard Grates |
|---|
| Sabbath Mode | Yes |
|---|
| Burner - Right Front | 15,000 BTU |
|---|
| Drawer Type | Storage |
|---|
| Style | Commercial |
|---|
| Overall Width | 29.875 in |
|---|
| App Filter - Convection | Yes |
|---|
| Control Type | Digital Temperature Display with Electronic Touchpad |
|---|
| Oven Rack Features | 3 Self-Clean Flat Oven Racks |
|---|
| Leveling System | 4 Leveling Legs |
|---|
| Cooktop Burner Grate Color | Matte Black |
|---|
| App Filter - Cooking Technology | Convection |
|---|
| Bake/Broiler BTU Rating - LP (000's BTU's) | 16.0 Bake / 13.5 Broiler |
|---|
| Oven Door Features | Big Clear View Oven Window, Frameless Oven Door |
|---|
| Oven Rack Positions (Single or Upper/Lower) | 6 |
|---|
| Height to Cooking Surface (in.) | 36 1/4 +/- 1/4 |
|---|
| OU Certified | No |
|---|
| Cooktop Burner Grate Features | Heavy-Cast Edge-to-Edge Grates |
|---|
| Ignition System | Electronic |
|---|
| Cabinet Width | 30 in |
|---|
| Connected Capabilities | Amazon Alexa, DiGiorno, Fresco, IFTTT, Innit, Sonos, The Google Assistant |
|---|
| Burner - Left Front | 21,000 BTU Tri-ring Burner |
|---|
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 21.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0 |
|---|
| Oven Control Features | Audible Preheat Signal, Auto Oven Shut-Off, Auto Self Clean, Automatic Oven Timer (Time Bake), Certified Sabbath Mode, Chef Connect, Control Lock Capability, Delay Bake Option (Time Bake), Delay Clean Option, Digipad Numeric Entry, Electronic Clock and Timer, Front Controls, In-Oven Broiling, Self-Clean Cool Down Time Display, Temperature Probe |
|---|
| App Filter - WiFi Connect | Built-In |
|---|
| Oven Cleaning Type | Self-Clean with Steam Clean Option |
|---|
| Configuration | Range with Storage Drawer |
|---|
| App Filter - Tri-Ring Burner | Yes |
|---|
| WiFi Connect | Built-In |
|---|
| Cooktop Surface | Deep Recessed, Stainless Steel |
|---|
| Grates | Included Center Grate |
|---|
| Total Capacity (cubic feet) | 5.6 cu ft |
|---|
| App Filter - Drawer Type | Storage |
|---|
| Convection Wattage | 1200W |
|---|
| Parts Warranty | Limited 1-year entire appliance |
|---|
| Cleaning Time | Variable with Delay Clean Option |
|---|
| Overall Depth | 29.375 in |
|---|
| Dishwasher Safe Knobs | Yes |
|---|
| App Filter - Cleaning Type | Self-Clean |
|---|
| App Filter - Edge-to-Edge Cooktop | Yes |
|---|
| Air Fry Basket | Optional- JXAFTRAY1VSS |
|---|
| Depth with Door Open | 47.5 in |
|---|
| Burner - Center | 9,500 BTU Front / 9,500 BTU Rear |
|---|
| Approximate Shipping Weight | 244 lb |
|---|
| Burner - Right Rear | 12,000 BTU |
|---|
| Oven Cooking Modes | Baked Goods, Convection Bake, Convection Roast, Frozen Pizza Multi Rack, Frozen Pizza Single Rack (No Preheat), Frozen Snacks Multi Rack, Frozen Snacks Single Rack (No Preheat), No Preheat Air Fry, Proof, Warming |
|---|
| Handle Design | Café Minimal |
|---|
| App Filter - Cooktop Type | Standard Grates |
|---|
| Control Knobs | Stainless Steel Appearance, Weighted |
|---|
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
|---|
| Overall Height | 37.375 in |
|---|
| Cooking Technology | Convection |
|---|
| Oven Interior | 1 Oven Interior Light, Black |
|---|
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Bake / 16.5 Broiler |
|---|
| Fuel Type | Natural Gas (factory set) |
|---|
| Net Weight | 224 lb |
|---|
| Grill | Integrated Cast Iron, JXCGRILL1, Optional |
|---|
| App Filter - Fuel Type | Gas |
|---|
| Product Type | Slide-In Single Oven |
|---|
| Depth Without Handle | 26.875 in |
|---|
| Cooktop Burner Grate Material | Cast-Iron |
|---|
| Labor Warranty | Limited 1-year entire appliance |
|---|
| LP Conversion Kit | Included |
|---|
| Warranty Notes | See written warranty for full details |
|---|
| Top Burner BTU Rating - LP (000's BTU's) | (1) 18.0 Tri-Ring; (1) 15.0; (1) 12.0; (2) 9.5; (1) 5.0; |
|---|
| Cooking System | True Convection |
|---|
| Handle Color | Stainless Steel |
|---|
| App Filter - Product Type | Ranges Slide-In Single Oven |
|---|
| Control Location | Front controls |
|---|
| Color Appearance | Platinum Glass |
|---|
| Griddle | Included, Integrated Cast Iron |
|---|
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19-1/2 x 20-5/8 |
|---|
| Valves (Degree of Turn) | 270 |
|---|
| Self-Clean Oven Door Lock | Automatic |
|---|
| App Filter - Cabinet Width | Cooking 30 in. (Standard) |
|---|
| App Filter - Control Type | Electronic touchpad |
|---|
| Trim Kit | JXFILLR1SS, Optional |
|---|
| Burner - Left Rear | 5,000 BTU Precise Simmer |
|---|
| Installation | Flush Appearance, Free-standing cut-out |
|---|
| Cooktop Burner Type | Sealed |
|---|
