Product Description
Innovation Extra-large cooking surfaces allow for tailored cooking zones, place your cookware wherever you want on the Liberty® cooking zone MoveMode® feature allows easy transfer of settings HeatShift® feature has three preset heat zones that allows you to change the power level by simply moving the pot across the cooking zone CookSmart® with 5 pre-set temperature levels Wi-Fi connectivity allows the cooktop and matching hood to communicate with one another to synchronize turning on task lighting and ventilation Performance 5 induction cooking elements Left and right Liberty® zones can be used as 2 separate cooking zones or combined into one large zone Automatic pan recognition Control panel lock 2 stage residual heat indicators PowerBoost® setting Control panel pause Design Full stainless steel frame Titanium grey glass color is a perfect match to Masterpiece® series ovens
Features
- The innovative Liberty® induction cooktop is designed for greater flexibility when cooking
- Three Extra-Large Liberty® cooking zones : allows more space and flexibility in placing larger cookware.
- HeatShift® : divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot. Perfect for recipes that require moving from a sauté to a simmer.
- MoveMode® : easily move your pot across the cooktop, and the power level will automatically transfer.
- PowerBoost® : increases element power by up to 50%, saving time to heat up pots or boil water quicker.
- CookSmart® : ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
Specifications
| Highlights | 17 power levels, 5 frying levels, Direct Select 2.0, flexInduction, fryingSensor Plus, powerBoost |
|---|
| Number of electric cooking zones | 5 |
|---|
| Automatic programmes | Yes |
|---|
| Additional Image 4 | https |
|---|
| EAN code | 825225960270 |
|---|
| Depth of the packed product (mm) | 1076 |
|---|
| Maximum height for installation (mm) | 508 |
|---|
| Power of 6th heating element (kW) | 3.3 |
|---|
| Frequency (Hz) | 60 |
|---|
| Sealed Burners | No |
|---|
| Energy input | Electric |
|---|
| Plate on indicator | 0 |
|---|
| SKU | CIT367YGS |
|---|
| Gross weight (kg) | 28.7 |
|---|
| Additional Image 2 | https |
|---|
| Power Cord Length | 37'' |
|---|
| Location of 3rd heating element | back left |
|---|
| Total number of cooktop burners | 5 |
|---|
| Additional Image 5 | https |
|---|
| Number of electric elements | 0 |
|---|
| Product packaging dimensions (HxWxD) | 7 1/16'' x 42 1/8'' x 26 3/4'' |
|---|
| dishwasher safe pan support | No |
|---|
| Location of 4th heating element | middle back |
|---|
| Type of 6th heating element | Induction heating |
|---|
| Location of 2nd heating element | center left |
|---|
| Height of the packed product (mm) | 172 |
|---|
| Depth for installation (mm) | 98 |
|---|
| Power of 2nd heating element (kW) | 3.3 |
|---|
| Dimension of 6th heating element (mm) | 380 x 215 |
|---|
| Construction type | Built-in |
|---|
| Type of lid | Without |
|---|
| Minimum width for installation (mm) | 883 |
|---|
| Type of control | Electronic |
|---|
| Power cord length (cm) | 96.0 |
|---|
| Power on indicator | No |
|---|
| Required cutout size (HxWxD) | 3 7/8'' x 34 7/8'' x 20'' |
|---|
| Number of halogen elements | 0 |
|---|
| Minimum distance from rear wall | 2'' |
|---|
| Maximum width for installation (mm) | 886 |
|---|
| Type of control | Direct Select 2.0;Front;TouchControl Basic Timer |
|---|
| Minimum distance from counter front | 2 1/4'' |
|---|
| Plug type | No Plug |
|---|
| Overall appliance dimensions (HxWxD) | 3/8''+3 7/8'' x 37'' x 21 1/4'' |
|---|
| Burners with booster | All |
|---|
| Power of 2nd heating element (kW in boost) | 3.6 |
|---|
| Number of electric warming zones | 0 |
|---|
| Volts (V) | 208-240 |
|---|
| UPC code | 825225960270 |
|---|
| Type of regulation | Stepless energy regulated |
|---|
| Optional accessories | TEPPAN1013, TEPPAN1016, TGRILLPANX, TROASTERT |
|---|
| Width of the packed product (mm) | 608 |
|---|
| Power of 6th heating element (kW in boost) | 3.6 |
|---|
| Color of frame | Stainless Steel |
|---|
| Gross weight | 63.000 |
|---|
| Net weight (kg) | 23.3 |
|---|
| Number of induction elements | 5 |
|---|
| Safety device | Auto Safety Shutoff;Childproof Lock;Panel Lock;pan recognition;Power Management Function |
|---|
| Additional Image 6 | https |
|---|
| Brand | Thermador |
|---|
| Timer | Yes |
|---|
| Current (A) | 50 |
|---|
| Net weight | 51.000 |
|---|
| Type of 2nd heating element | Induction heating |
|---|
| Power of 1st heating element (kW in boost) | [3.6] |
|---|
| Minimum height for installation (mm) | 505 |
|---|
| Dimension of 2nd heating element (mm) | 380 x 215 |
|---|
| Additional Image 1 | https |
|---|
| Product name / series name | Cooking zone ceramic |
|---|
| Product group | Hob |
|---|
| Location of control panel | Front |
|---|
| Location of 6th heating element | center right |
|---|
| Number of gas burners | 0 |
|---|
| Additional Image 3 | https |
|---|
| Location of the heating element | front left |
|---|
| Number of radiant elements | 0 |
|---|
| Type of frame | Convenience frame |
|---|
| Main on/off switch | Yes |
|---|
| Location of 5th heating element | back right |
|---|
| Internal article number | CIT367YGS |
|---|
| Ignition system | No |
|---|
