Product Description
Innovation Extra-large cooking surfaces allow for tailored cooking zones, place your cookware wherever you want on the Liberty® cooking zone HeatShift® feature has three preset heat zones that allows you to change the power level by simply moving the pot across the cooking zone MoveMode® feature allows easy transfer of settings CookSmart® with 5 pre-set temperature levels Wi-Fi connectivity allows the cooktop and matching hood to communicate with one another to synchronize turning on task lighting and ventilation Performance 5 induction cooking elements Left and right Liberty® zones can be used as 2 separate cooking zones or combined into one large zone 17 power levels Automatic pan recognition Control panel lock PowerBoost® setting 2 stage residual heat indicators Control panel pause Design Silver mirrored glass color offers the perfect companion solution for stainless steel products Illuminated touch controls Front controls Full stainless steel frame
Features
- The innovative Liberty® induction cooktop is designed for greater flexibility when cooking
- Three Extra-Large Liberty® cooking zones : allows more space and flexibility in placing larger cookware.
- HeatShift® : divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot. Perfect for recipes that require moving from a sauté to a simmer.
- MoveMode® : easily move your pot across the cooktop, and the power level will automatically transfer.
- PowerBoost® : increases element power by up to 50%, saving time to heat up pots or boil water quicker.
- CookSmart® : ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
Specifications
| Number of electric elements | 0 |
|---|
| Net weight | 51.000 |
|---|
| Minimum width for installation (mm) | 883 |
|---|
| Type of 2nd heating element | Induction heating |
|---|
| Highlights | 17 power levels, 5 frying levels, Direct Select 2.0, flexInduction, fryingSensor Plus, powerBoost |
|---|
| Additional Image 2 | https |
|---|
| Height of the packed product (mm) | 172 |
|---|
| Volts (V) | 208-240 |
|---|
| Power cord length (cm) | 96.0 |
|---|
| Type of frame | Convenience frame |
|---|
| Power of 2nd heating element (kW in boost) | 3.6 |
|---|
| SKU | CIT367YMS |
|---|
| Main on/off switch | Yes |
|---|
| Type of lid | Without |
|---|
| Maximum width for installation (mm) | 886 |
|---|
| Product group | Hob |
|---|
| Product name / series name | Cooking zone ceramic |
|---|
| Gross weight (kg) | 28.7 |
|---|
| Depth of the packed product (mm) | 1076 |
|---|
| Location of 3rd heating element | back left |
|---|
| Type of control | Electronic |
|---|
| Power of 1st heating element (kW in boost) | [3.6] |
|---|
| Plate on indicator | 0 |
|---|
| Burners with booster | All |
|---|
| Overall appliance dimensions (HxWxD) | 3/8''+3 7/8'' x 37'' x 21 1/4'' |
|---|
| Additional Image 1 | https |
|---|
| Internal article number | CIT367YMS |
|---|
| Power on indicator | No |
|---|
| Additional Image 3 | https |
|---|
| Type of regulation | Stepless energy regulated |
|---|
| Location of 6th heating element | center right |
|---|
| UPC code | 825225961444 |
|---|
| Location of 2nd heating element | center left |
|---|
| Current (A) | 50 |
|---|
| Power of 6th heating element (kW) | 3.3 |
|---|
| Dimension of 6th heating element (mm) | 380 x 215 |
|---|
| Construction type | Built-in |
|---|
| Total number of cooktop burners | 5 |
|---|
| Sealed Burners | No |
|---|
| Type of 6th heating element | Induction heating |
|---|
| Power of 2nd heating element (kW) | 3.3 |
|---|
| Ignition system | No |
|---|
| Optional accessories | TEPPAN1013, TEPPAN1016, TGRILLPANX, TROASTERT |
|---|
| Additional Image 7 | https |
|---|
| Brand | Thermador |
|---|
| Depth for installation (mm) | 98 |
|---|
| Additional Image 6 | https |
|---|
| Color of frame | Stainless Steel |
|---|
| Automatic programmes | Yes |
|---|
| Minimum height for installation (mm) | 505 |
|---|
| Number of gas burners | 0 |
|---|
| Additional Image 5 | https |
|---|
| Frequency (Hz) | 60 |
|---|
| Timer | Yes |
|---|
| Type of control | Direct Select 2.0;Front;TouchControl Basic Timer |
|---|
| Dimension of 2nd heating element (mm) | 380 x 215 |
|---|
| Gross weight | 63.000 |
|---|
| Net weight (kg) | 23.3 |
|---|
| Product packaging dimensions (HxWxD) | 7 1/16'' x 42 1/8'' x 26 3/4'' |
|---|
| Width of the packed product (mm) | 608 |
|---|
| Energy input | Electric |
|---|
| Basic surface material | Ceramic with Stainless Steel |
|---|
| Minimum distance from rear wall | 2'' |
|---|
| EAN code | 825225961444 |
|---|
| Number of induction elements | 5 |
|---|
| Maximum height for installation (mm) | 508 |
|---|
| Required cutout size (HxWxD) | 3 7/8'' x 34 7/8'' x 20'' |
|---|
| Power Cord Length | 37'' |
|---|
| Location of 4th heating element | middle back |
|---|
| Minimum distance from counter front | 2 1/4'' |
|---|
| Plug type | No Plug |
|---|
| Number of halogen elements | 0 |
|---|
| Location of the heating element | front left |
|---|
| Safety device | Auto Safety Shutoff;Childproof Lock;Panel Lock;pan recognition;Power Management Function |
|---|
| Number of electric cooking zones | 5 |
|---|
| Location of 5th heating element | back right |
|---|
| Number of radiant elements | 0 |
|---|
| Location of control panel | Front |
|---|
| Power of 6th heating element (kW in boost) | 3.6 |
|---|
| dishwasher safe pan support | No |
|---|
| Additional Image 4 | https |
|---|
| Number of electric warming zones | 0 |
|---|
