Product Description
Performance 24" depth extends capture area to ensure removal of smoke and odor Select the precise fan speed needed with four different settings Automatic mode detects temperatures to adjust fan speed automatically 10-min delay shut off ensure lingering odor do not interrupt a course Check filter reminder light illuminates after 40 hours of operation Powerfully Quiet® blowers sold separate and needed to complete install Remote or inline blowers to reduce noise, integral for top performance 10" round duct discharge Design Design match to Thermador Professional Series ranges and range tops Sleek, smooth touch control make cleaning easy with a damp cloth Beautiful illumination with white multiple level LED lighting Dishwasher-safe stainless steel, commercial-style baffle filters 6" tall duct cover accessory available, sold separate 18"-35" tall telescopic duct cover accessory available, sold separate 42"-59" tall telescopic duct cover accessory available, sold separate Built-in remote control panel accessory available, sold separate
Features
- Professional Chimney Wall Hoods create a crafted, sculpted focal point that completes the ultimate cooking system
- Powerfully Quiet® system : accepts integral, inline, and remote blowers so you can choose the installation that is best and reduce noise while hood is in use. Ventilation should be seen, not heard.
- Delay Shut Off & Automatic Mode : features an Automatic Mode, that adjusts the fan speed according to your cooking style, as well as Delay Shut Off, which runs the hood 10 minutes after you are done cooking to remove any lingering odors.
- LED Lighting : highlights your meal from first course to last with multi-level vivid LED Lighting.
- Sleek Electronic Touch Control Panel : convenient control that is easy-to-use and easy-to-clean.
Specifications
| Power cord length (cm) | 0.0 |
|---|
| Required distance above cooktop/ranges | 30''/30'' |
|---|
| Design | Wall chimney hood |
|---|
| Diameter of air duct top | 10 |
|---|
| Plug type | Fixed Connection, No Plug |
|---|
| Total output power of the motors | 0 |
|---|
| SKU | HPCN48WS |
|---|
| Power Cord Length | 0" |
|---|
| Product packaging dimensions (HxWxD) | 29 1/4" x 52 3/8" x 23 3/16" |
|---|
| Remote control | Yes |
|---|
| Number of lights | 4 |
|---|
| Additional Image 2 | https |
|---|
| Optional accessories | CHMHP486W, CHMHP48TW, CHMHP48XTW, REMCPW |
|---|
| Additional Image 1 | https |
|---|
| Product group | Hood |
|---|
| Material chimney | Stainless steel |
|---|
| Construction type | Built-in |
|---|
| Typology | Wall-mounted |
|---|
| Number of speed settings | 4-stage |
|---|
| Gross weight (kg) | 45.0 |
|---|
| Watts (W) | 1428 |
|---|
| Frequency (Hz) | 60 |
|---|
| Diameter of air duct (mm) | 250 |
|---|
| Light Control Type | Continuous |
|---|
| Net weight | 91.000 |
|---|
| Volts (V) | 120 |
|---|
| Depth of the packed product (mm) | 1330 |
|---|
| Odour filter | No |
|---|
| Net weight (kg) | 41.1 |
|---|
| Air exhaust | Yes |
|---|
| UPC code | 825225931577 |
|---|
| Height of product, without chimney (mm) | 457 |
|---|
| Height of the packed product (mm) | 743 |
|---|
| Total luminance (lux) | 150 |
|---|
| No-return airflow flap | Yes |
|---|
| Current (A) | 15 |
|---|
| Clean filter reminders | Yes |
|---|
| Overall appliance dimensions (HxWxD) | 18" x 47 15/16" x 24'' |
|---|
| Width of the packed product (mm) | 589 |
|---|
| Number of motors | 0 |
|---|
| Brand | Thermador |
|---|
| Color body | Stainless Steel |
|---|
| Motor location | Without motor |
|---|
| Grease filter material | Washable stainless steel |
|---|
| Type of control | Illuminated Buttons;Touch Control |
|---|
| Type of manual control devices | touch control |
|---|
| Type of lamps used | Low consumption |
|---|
| Installation type | Wall-mounted |
|---|
| Gross weight | 99.000 |
|---|
| Internal article number | HPCN48WS |
|---|
| Type of control | Electronic |
|---|
| EAN code | 825225931577 |
|---|
