John Deere X330 Lawn Tractor with 42-in. Deck

  • SKU JDX33042
IN STORE ONLY
Check In-Store Availability

Need help? Click here to contact our Outdoor Power Sales Team.

Add to Cart

Product Description

John Deere X330 Lawn Tractor with 42-in. Deck is a reliable and powerful machine designed for homeowners who demand performance and versatility. Equipped with a 22-hp (16.4-kW) Cyclonic engine, this lawn tractor ensures smooth operation and high efficiency.

Features:

  • The 42-in. (107-cm) Accel Deepâ„¢ Mower Deck, compatible with the optional MulchControlâ„¢ kit featuring one-touch technology, delivers a superior cut and easy conversion between mulching and side discharge.
  • The Twin Touchâ„¢ forward and reverse foot pedals provide precise control and ease of use, while the four-year/300-hour bumper-to-bumper warranty gives you peace of mind with your purchase.
  • This model is equipped with features that make snow removal efficient, adding to its versatility as an all-season tool.

View Brochure

Model Number: 4694M



Model may be pictured with optional features. Additional options may be available to add for an additional price.
Looking for John Deere equipment? We are a certified John Deere dealer with all the equipment, accessories, and parts you need to maintain your perfect lawn. Does your mower or tractor need servicing or repair? Schedule a service appointment and one of our trained experts will get it running like new. Near downtown Hartville, our location is perfect for Stark, Summit, and Portage County residents in Hartville, Uniontown, Alliance, Mogadore, Jackson Township, and the Canton area, including North Canton.

Specifications

Engine:

  • Power: 22 hp / 16.4 kW
  • Displacement: 44.2 cu in. / 724 cc
  • Manufacturer/model: 44J6 Cyclonic
  • Type: Overhead valve, full-pressure lube, oil filter
  • Cylinders: V-twin, cast-iron liners
  • Governor: Mechanical
  • Choke/speed control: Separate levers, automatic choke return
  • Cooling method: Air
  • Air cleaner: Dry, replaceable
  • Oil change: No-tools oil drain hose with replaceable filter

Fuel System:

  • Type: Gasoline
  • Fuel delivery: Pulse pump, carburetor
  • Fuel gauge: Gauge on dash
  • Fuel tank location: Rear
  • Fuel fill opening: On left fender, 3 in. / 7.6 cm
  • Fuel tank capacity: 3.3 U.S. gal. / 12.5 L

Electrical System:

  • Battery: 12 V / 340 CCA
  • Charging system: Flywheel alternator, regulated, 14 amp
  • Engine starter: Bendix
  • Hour meter: Yes
  • Headlights: Two standard, incandescent, 27 W
  • Taillights or reflector: No
  • Backup lights: No
  • Rear work lights: No
  • 12-V outlet: Optional

Transaxle:

  • Type: K46 hydrostatic integrated with transaxle
  • Control: Twin Touchâ„¢ pedals
  • Cruise control: Yes, button on dash
  • Oil cooler: Fins and fan on transaxle
  • Oil filter: Internal, not replaceable
  • Differential lock: No
  • Forward speed: 0-5.5 mph / 0-8.9 km/h
  • Reverse speed: 0-4 mph / 0-6.4 km/h
  • Brakes: Internal wet disc

Chassis:

  • Frame: Welded heavy-duty
  • Primer/paint: E-coat/powder
  • Weight bracket: Standard rear, optional front
  • Receiver hitch: No
  • Front axle: Cast iron front axle, front wheel ball bearings
  • Spindle bushings: No
  • Front tires: 15x6-6
  • Rear tires: 20x10-8
  • Hood material: Fully enclosed, molded-in color material reduces sound, will not rust or dent
  • Fender deck material: Stamped steel
  • Floor mats: Sure-grip rubber
  • Storage: Yes, under seat and covered toolbox
  • Service interval decal: Yes
  • Fender handles/grips: No
  • Cup holder: Yes
  • Equipment mounting: Yes, heavy duty
  • Maximum towing capacity: 600 lb / 272 kg

Steering:

  • Type: Manual, sector and pinion
  • Four-wheel steer: Not available on this model
  • Steering wheel: Large, 14 in. / 35.6 cm
  • Tilt steering wheel: No
  • Turning radius: 16 in. / 40.6 cm
  • Uncut circle radius: 26 in. / 66 cm

Seat:

  • Type: Open-back design with grasp
  • Seat back height: 15 in. / 38 cm
  • Armrests: No
  • Fore-aft adjustment: While seated, ball bearing slide rail, 15-position, 6.6 in. / 17 cm
  • Seat suspension: Tilt, two coil springs, three-position no-tools adjustment for operator weight

Lift System:

  • Type: Foot pedal with optional adjustable spring assist kit
  • Mower cut height: 13 positions, 1-4 in. / 2.5-10.2 cm
  • Cut height increments: 0.25 in. / 0.64 cm
  • Preset cut height: Yes

Mower Deck:

  • Type: Side discharge
  • Cutting width: Accel Deepâ„¢ mower deck, 42 in. / 107 cm
  • Construction: Stamped steel deck shell
  • Mower deck material: 12 gauge / 0.105 in. / 2.7 mm
  • Mower wash port: Yes
  • Mower drive system: Electric power take-off (PTO) clutch, in-line belt
  • Mower wheels: Two
  • Mower wheel adjustment: Four-position, tool required
  • Mower level adjustment: Exact Adjust ports and onboard deck-leveling gauge

Mower Attachability:

  • Type: Slide under tractor
  • Front draft arms: Attached with spring pins at two points
  • Rear draft arms: Two pins and spring clips
  • Mower wheels rotate: No
  • Drive system: Single belt

Safety:

  • Meets ANSI standard: Yes
  • Meets OPEI standard: Yes
  • Backup protection: Reverse Implement Option (RIO)
  • Safety video: Yes

Dimensions:

  • Height: 46.1 in. / 1171 mm
  • Overall length: 71.5 in. / 1817 mm
  • Wheelbase: 49.4 in. / 1255 mm
  • Width with mower: 50.5 in. / 1283 mm
  • Width with mower (deflector raised for storage): 51.2 in. / 1300 mm
  • Width without mower: 38 in. / 964 mm
  • Weight: Mower, no fuel: 542 lb / 246 kg

Manuals

Misplace the user manual? No problem! Hartville Hardware is here to help. Below is the user manual for the John Deere X330 Lawn Tractor. Read it before you buy it, or come back and download it if you have any questions after getting your product home.

John Deere X330 Lawn Tractor Manual



Warranty & Certifications

John Deere offers a warranty for all Turf and Utility Equipment that they manufacture.

Each piece of equipment carries a specific warranty including a specific warranty period. Please contact your Hartville Hardware Outdoor Power Sales Team Member for more details.

Related Products

  • Primary Air Filter: MIU14496
  • Secondary Air Filter: MIU14395
  • Ignition Key: GY20680
  • Control Lever Throttle Cable: AM147130
  • Battery (Wet Charged, For Canada and USA): TY25221B
  • Battery (Wet Charged, For USA and Canada): TY25878B
  • Rotary Switch: AM133597
  • Fuel Filter: AM116304
  • Spark Plug: MIU11020
  • Traction Belt Drive: UC35484
  • Home Maintenance Kit: LG277
  • Filler Cap: AM141406
  • Plunger Switch: AUC12129
  • Reverse Implement Push Switch: AUC12828
  • Multi-Purpose HD Lithium Complex Grease: TY24416
  • Grease Gun: TY26518
  • Engine Oil (Plus-50â„¢ II 10W-30): TY22029
  • Oil Filter: AM125424
  • Muffler: AM147129
  • Mower Blade Kit (High Lift, Mulch): AM140973
  • Mower Blade Kit (Low Lift, Mulch): AM140332
  • V-Belt (Primary): M169485
  • V-Belt (Secondary): M174313
  • Mower Deck Leveling Gauge: AM130907
  • Gage Wheel: M111489
