Product Description
John Deere XUV590M Crossover Utility Vehicle is built for the toughest and muddiest trails. This utility vehicle can handle them with ease. The perfect combination between power and comfort.
Features:
Precision-engineered drive system optimizes acceleration, hauling, towing, and hill-climbing capabilities. Delivers quick acceleration and provides a top speed of more than 77 km/h (48 mph). Designed for all-day comfort with many vehicle conveniences. Large, extra-durable, one-piece cargo box ensures hard-driving performance and longevity. Four-wheel independent suspension provides unparalleled ride over challenging terrain and excellent handling through corners. Power steering for excellent handling characteristics and low steering effort. Occupant protective structure (OPS) and occupant side retention (OSR). Available in Green & Yellow, Olive & Black, or Camo.
View Brochure NOTE: Base model image shown. Does not include any additional accessories. Additional accessories can be added for an additional cost. Additional color options are available at an additional cost. Looking for John Deere equipment? We are a certified John Deere dealer with all the equipment, accessories, and parts you need to maintain your perfect lawn. Does your mower or tractor need serviced or repaired? Schedule a service appointment, and one of our trained experts will get it running like new. Near downtown Hartville, our location is perfect for Stark, Summit, and Portage County residents in Hartville, Uniontown, Alliance, Mogadore, Jackson Township, and the Canton area, including North Canton.
Specifications
Engine:
Power: 23.8 kW / 32 hp
Type: 4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV)
Displacement: 586 cc
Cooling System: Liquid cooled
Cargo Box:
Dimensions: 820 x 1209 x 297 mm / 32.3 x 47.6 x 11.7 in.
Capacity (Weight): 227 kg / 500 lb
Towing Capacity:
Suspension:
Front: Fully independent dual A-arm with adjustable coil-over shocks, 203 mm (8 in.) travel, anti-roll bar
Rear: Fully independent with lower A-arm and upper camber link with adjustable coil-over shocks, 203 mm (8 in.) travel
Final Drive:
Park, high, low, neutral, reverse transaxle
Four-Wheel Drive:
Dash switch actuated four-wheel drive system
Fuel Capacity:
Key Specs:
Type: 4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV)
Displacement: 586 cc
Power: 23.8 kW / 32 hp
Cooling System: Liquid cooled
Engine:
Type: 4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV)
Displacement: 586 cc
Power: 23.8 kW / 32 hp
Cooling System: Liquid cooled
Transmission:
Continuously Variable Transmission (CVT) with clutch enclosure
Final Drive:
Park, high, low, neutral, reverse transaxle
Four-Wheel Drive:
Dash switch actuated four-wheel drive system
Traction Assist: Limited slip front differential, Positive locking, switch actuated rear differential lock
Descent Control: No
Suspension:
Front: Fully independent dual A-arm with adjustable coil-over shocks, 203 mm (8 in.) travel, anti-roll bar
Rear: Fully independent with lower A-arm and upper camber link with adjustable coil-over shocks, 203 mm (8 in.) travel
Brakes:
Type: 196 mm (7.7 in.) ventilated four-wheel stainless-steel disc brakes with 34.93 mm (1.375 in.) diameter hydraulic twin-piston calipers
Park Brake: Park in-transmission
Tires / Wheels:
Front: 25x8-12 Terra Hawk all-terrain on steel wheels; 26x8-14 Maxxis® Bighorn® 2.0 extreme terrain on steel or alloy wheels
Rear: 25x10-12 Terrahawk AT (All Terrain) 4-ply rating steel wheels, various colors or 26x10-14 Maxxis Bighorn 2.0 6-ply rating aluminum alloy wheels, various colors or 26x10-14 Maxxis Bighorn 2.0 6-ply rating steel wheels, various colors
Dimensions / Capacities:
Wheelbase: 1.86 m / 72.8 in.
Weight: With fuel and fluids: 676 kg / 1491 lb
Length: 2870 mm / 113 in.
Width: 1435 mm / 56.5 in.
Height: 1867 mm / 73.5 in.
Tread Centers: Front: 1220 mm / 48 in.; Rear: 1168 mm / 46 in.
Ground Clearance: Minimum: 267 mm / 10.5 in.
Fuel Capacity: 28 L / 7.4 U.S. gal.
Cargo Box Dimensions: 820 x 1209 x 297 mm / 32.3 x 47.6 x 11.7 in.
Cargo Box Capacity (Weight): 227 kg / 500 lb
Payload Capacity: 408 kg / 900 lb
Towing Capacity: 680 kg / 1500 lb
Hitch: Standard 50 mm (2 in.) rear receiver with optional 50 mm (2 in.) front receiver with recovery loops
Electrical:
Battery: 12 V 340 CCA
Alternator: 65 amp
DC Outlet: 12 V
Instrumentation:
Digital display (gear position, system diagnostic light, speed, rpm, 4WD indicator, rear differential indicator, fuel level, coolant temperature, hour meter, miles, and service interval warning light)
Storage:
Two cupholders, sealed underhood storage, glove box
Seating:
Colors:
Green/yellow, olive/black, or TRUETIMBER® Kanati camo
Power Steering:
Manuals
Misplace the user manual? No problem! Hartville Hardware is here to help. Below is the user manual for the John Deere XUV590M Utility Vehicle . Read it before you buy it, or come back and download it if you have any questions after getting your product home.
John Deere XUV590M Utility Vehicle Manual
Warranty & Certifications
John Deere offers a warranty for all Turf and Utility Equipment that they manufacture.
Each piece of equipment carries a specific warranty including a specific warranty period. Please contact your Hartville Hardware Outdoor Power Sales Team Member for more details.
