Product Description
Features
- 5 Burners : 5 high-efficiency gas burners allow you to cook multiple dishes at once
- OptiSim® Burner : the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.
- Tilt & Stay legs for easy cleaning of cooktop - 1st in India
- Continuous Cast Iron Grates : makes it easy to slide pots & pans from burner to burner.
Specifications
| Power on indicator | Yes |
|---|
| Power of 3rd burner | 6000 |
|---|
| Type of control | Front;sword knobs |
|---|
| Number of halogen elements | 0 |
|---|
| Depth for installation (mm) | 97 |
|---|
| Additional Image 3 | https |
|---|
| Frequency (Hz) | 60 |
|---|
| Type of heating element | Gas |
|---|
| Type of regulation | Step energy regulated |
|---|
| Optional accessories | HEZ298102, HEZ9GR58UC |
|---|
| Internal article number | NGM5659UC |
|---|
| Product packaging dimensions (HxWxD) | 8 3/8'' x 43 1/8'' x 24 3/4'' |
|---|
| Total number of cooktop burners | 5 |
|---|
| Energy input | Gas |
|---|
| LP Gas Connection Rating | 41400 |
|---|
| Minimum width for installation (mm) | 887 |
|---|
| Additional Image 7 | https |
|---|
| Overall appliance dimensions (HxWxD) | 3 13/16'' x 37'' x 21 1/4'' |
|---|
| Width of the packed product (mm) | 610 |
|---|
| Height of the packed product (mm) | 210 |
|---|
| Location of 3rd heating element | back left |
|---|
| Number of radiant elements | 0 |
|---|
| Automatic programmes | No |
|---|
| Power of 5th burner | 10300 |
|---|
| Residual heat indicator | Without |
|---|
| Number of electric warming zones | 0 |
|---|
| Location of 2nd heating element | center left |
|---|
| Product name / series name | gas hob w integrated controls |
|---|
| Power of 3rd heating element (kW) | 1.75 |
|---|
| Power Cord Length | 40'' |
|---|
| Power of 6th burner | 6000 |
|---|
| Gas connection rating (W) | 12100 |
|---|
| Location of 6th heating element | center right |
|---|
| Product group | Hob |
|---|
| Type of control | Mechanical |
|---|
| Location of control panel | Front |
|---|
| Current (A) | 15 |
|---|
| Gross weight (kg) | 14.1 |
|---|
| Number of gas burners | 5 |
|---|
| Power cord length (cm) | 101.6 |
|---|
| Location of the heating element | front left |
|---|
| Maximum height for installation (mm) | 486 |
|---|
| Knob Material | Full metal |
|---|
| Sealed Burners | Yes |
|---|
| Type of 3rd heating element | Gas |
|---|
| Included accessories | 1 x nozzle set for liquid gas, 3 x cast iron pan support |
|---|
| Highlights | Wok burner |
|---|
| Minimum distance from rear wall | 3'' |
|---|
| Power of the heating element | 1 |
|---|
| Alternative gas type | Liquid gas 27,5 mbar (USA) |
|---|
| Main on/off switch | No |
|---|
| Number of induction elements | 0 |
|---|
| Total BTU load | 41400 |
|---|
| Net weight | 12.000 |
|---|
| Timer | No |
|---|
| Maximum width for installation (mm) | 887 |
|---|
| Basic surface material | Stainless Steel |
|---|
| Location of 4th heating element | middle back |
|---|
| Additional Image 6 | https |
|---|
| Net weight (kg) | 5.5 |
|---|
| Safety device | Thermo-electric |
|---|
| Additional Image 1 | https |
|---|
| dishwasher safe pan support | No |
|---|
| EAN code | 4242005455102 |
|---|
| Number of Single grates | 1 |
|---|
| Brand | Bosch |
|---|
| Minimum height for installation (mm) | 486 |
|---|
| UPC code | 825225972594 |
|---|
| Power of 5th heating element (kW) | 3 |
|---|
| Additional Image 2 | https |
|---|
| Gas type | Natural gas 15 mbar (USA) |
|---|
| Plug type | 120V-3 prong |
|---|
| Location of gas connection | Bottom, Rear, Right |
|---|
| Depth of the packed product (mm) | 1020 |
|---|
| Gross weight | 31.000 |
|---|
| SKU | NGM5659UC |
|---|
| Number of Double grates | 2 |
|---|
| Required cutout size (HxWxD) | 3 13/16'' x 34 15/16'' x 19 1/8'' |
|---|
| Type of safety device for gas | Electromagnetic for each burner |
|---|
| Ignition system | Yes |
|---|
| Number of electric cooking zones | 0 |
|---|
| Number of electric elements | 0 |
|---|
| Volts (V) | 120 |
|---|
| Additional Image 4 | https |
|---|
| Type of 5th heating element | Gas |
|---|
| Type of lid | Without |
|---|
| Plate on indicator | 0 |
|---|
| Construction type | Built-in |
|---|
| Additional Image 5 | https |
|---|
| Minimum distance from counter front | 1 7/8'' |
|---|
| Color of frame | Stainless Steel |
|---|
| Power of 1st burner | 3400 |
|---|
| Location of 5th heating element | back right |
|---|
