| Oven Rack Features | 3 Self-Clean Oven Racks |
|---|
| Configuration | Range with Smooth Glide Storage Drawer |
|---|
| Trim Kit | JXFILLR1SS, Optional |
|---|
| Cooking Technology | True European Convection with Precise Air |
|---|
| WiFi Enabled Features | Baked Goods, Convection Roast, Enhanced Temp Probe, Frozen Pizza Multi Rack, Frozen Pizza Single Rack, Frozen Snacks Multi Rack, Frozen Snacks Single Rack, No Preheat Air Fry, Remote Control, Remote Notifications, Scan To Cook (Oven) |
|---|
| Grill | Included, JXGRILL1 |
|---|
| OU Certified | No |
|---|
| Oven Cleaning Type | Self-Clean, Steam Clean |
|---|
| Burner - Right Rear | 9,500 BTU |
|---|
| Cooktop Burner Type | Sealed |
|---|
| Overall Height | 36.5 in |
|---|
| Overall Width | 30 in |
|---|
| App Filter - Cooktop Type | Standard Grates |
|---|
| App Filter - Cabinet Width | Cooking 30 in. (Standard) |
|---|
| Handle Color | Stainless Steel |
|---|
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19 x 20-5/8 |
|---|
| Handle | Designer Style |
|---|
| App Filter - Control Type | Electronic touchpad |
|---|
| Height to Top of Rear Vent Trim | 37.625 in |
|---|
| Warranty Notes | See written warranty for full details |
|---|
| Optional Accessories | WB48X20990 Roller Rack |
|---|
| Cooktop Burner Grate Features | Edge-to-Edge Grates |
|---|
| Griddle | Reversible Cast Grill/Griddle |
|---|
| Oven Interior | 1 Incandescent Light, Black |
|---|
| Connected Capabilities | Amazon Alexa, DiGiorno, Fresco, IFTTT, Innit, Sonos, The Google Assistant |
|---|
| Depth with Door Open | 47.5 in |
|---|
| Bake Wattage | 2850W |
|---|
| Ignition System | Electronic |
|---|
| Overall Depth | 29.5 in |
|---|
| Cooktop Type | Standard Grates |
|---|
| Burner - Left Front | 21,000 BTU Tri-ring Burner |
|---|
| LP Conversion Kit | Included |
|---|
| Cabinet Opening | 30 in |
|---|
| App Filter - Tri-Ring Burner | Yes |
|---|
| Cooktop Burner Grate Color | Matte Black |
|---|
| Dual Ring Burners | Yes |
|---|
| Sabbath Mode | Yes |
|---|
| Depth Without Handle | 26.875 in |
|---|
| Parts Warranty | Limited 1-year entire appliance |
|---|
| Product Type | Slide-In Single Oven |
|---|
| Amp Rating at 208V | 30 |
|---|
| App Filter - Product Type | Ranges Slide-In Single Oven |
|---|
| Installation | Flush Appearance, Free-standing cut-out |
|---|
| Broiler Wattage | 4000W |
|---|
| Air Fry Basket | Optional- JXAFTRAY1VSS |
|---|
| WiFi Connect | Built-In |
|---|
| App Filter - Drawer Type | Storage |
|---|
| App Filter - Fuel Type | Dual Fuel |
|---|
| Height to Cooking Surface (in.) | 36 1/4 +/- 1/4 |
|---|
| App Filter - Cleaning Type | Steam and Self-Clean |
|---|
| Total Capacity (cubic feet) | 5.7 cu ft |
|---|
| Amp Rating at 240V | 30 |
|---|
| Burner - Center | 9,500 BTU Dual Oval |
|---|
| Burner - Left Rear | 5,000 BTU Precise Simmer |
|---|
| Control Type | Glass Touch |
|---|
| Top Burner BTU Rating - LP (000's BTU's) | (1) 18.0; (1) 15.0; (2) 9.5; (1) 5.0 |
|---|
| KW Rating at 208V | 2.7 |
|---|
| App Filter - Cooking Technology | Convection |
|---|
| Net Weight | 236 lb |
|---|
| Approximate Shipping Weight | 256 lb |
|---|
| Volts/Hertz/Amps | 208/240V; 60Hz; 30A |
|---|
| Oven Door Features | Big View Oven Window |
|---|
| Cooktop Surface | Deep Recessed, Edge-to-Edge, Stainless Steel |
|---|
| KW Rating at 240V | 3.6 |
|---|
| Color Appearance | Fingerprint Resistant Stainless |
|---|
| Burner - Right Front | 15,000 BTU |
|---|
| Cabinet Width | 30 in |
|---|
| Oven Control Features | Audible Preheat Signal, Auto Recipe Conversion, Auto Self Clean, Certified Sabbath Mode, Control Lock Capability, Convection Bake, Convection Roast, Dual Broil, Electronic Clock & Kitchen Timer, Front Controls, In-Oven Broiling, Temperature Probe |
|---|
| Self-Clean Oven Door Lock | Automatic |
|---|
| Control Knobs | Stainless Steel Appearance, Weighted |
|---|
| Oven Cooking Modes | Bake, Broil, Convection Bake, No Preheat Air Fry, Proof, Warming |
|---|
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 21.0 (1) 15.0; (2) 9.5; (1)5.0 |
|---|
| App Filter - Convection | Yes |
|---|
| Fuel Type | Dual Fuel |
|---|
| Power Connection | Power Cord - Not Included |
|---|
| Cooktop Burner Grate Material | Heavy Cast Iron |
|---|
| Drawer Type | Storage |
|---|
| Labor Warranty | Limited 1-year entire appliance |
|---|
