Product Description
Innovation Exclusive, patented Star® Burner – most even heating, unsurpassed flame coverage Raised pedestal burner and porcelain maintop for effortless cleaning Performance Professional style, continuous cast iron grates Continuous porcelain, easy to clean cooking surface Electronic re-ignition will automatically re-ignite the burner in case the flame goes out ExtraLow® feature provides a wide range of temperature control, perfect for simmering delicate sauces Superior griddle results-6 pass, 1630 watt electric griddle Design Bold Professional design Patented Pedestal Star® Burner with QuickClean Base™ Restaurant style metal knobs Every front burner 18,000 BTU (NG) Non-stick, rust-proof cast-aluminum griddle removable for easy cleaning Griddle is convertible to grill with optional accessory
Features
- Non-stick griddle and Star® Burners with QuickClean Base® deliver superior power and heat distribution with effortless cleaning
- Star® Burners : Our patented five-point design provides equal flame distribution for even cooking.
- ExtraLow® Burners : 2 burners offer precise settings that are perfect for simmering meals or melting chocolate without burning.
- Non-Stick Griddle : Deliver consistent even heating across a flat large surface with easy removal for cleaning.
- 18,000 BTU Star® Burners : These extra high heat burners across the front are optimal for rapid boiling and high heat searing.
- LED Down Lighting : clearly illuminate the control panel with ample lighting.
Specifications
| dishwasher safe pan support | No |
|---|
| Location of 4th heating element | center right |
|---|
| Brand | Thermador |
|---|
| Power of the heating element | 5.27 |
|---|
| Type of regulation | Step energy regulated |
|---|
| Basic surface material | Porcelain, Steel |
|---|
| Automatic programmes | Yes |
|---|
| Frequency (Hz) | 60 |
|---|
| Total BTU load | 108000 |
|---|
| Net weight (kg) | 66.8 |
|---|
| Location of 5th heating element | back right |
|---|
| Width of the packed product (mm) | 1030 |
|---|
| SKU | PCG486WD |
|---|
| Residual heat indicator | Without |
|---|
| Product packaging dimensions (HxWxD) | 20 1/2" x 53 1/4" x 40 1/2" |
|---|
| Depth for installation (mm) | 268 |
|---|
| Location of 2nd heating element | back left |
|---|
| Safety device | Electronic flame failure safety device |
|---|
| Type of control | Front;sword knobs |
|---|
| Height of the packed product (mm) | 520 |
|---|
| Ignition system | Yes |
|---|
| Additional Image 5 | https |
|---|
| Overall appliance dimensions (HxWxD) | 10 9/16'' x 47 15/16'' x 25 13/16'' |
|---|
| Type of 5th heating element | Gas |
|---|
| Gas connection rating (W) | 31620 |
|---|
| Type of 2nd heating element | Gas |
|---|
| Location of gas connection | Bottom, Rear, Right |
|---|
| Location of the heating element | front left |
|---|
| Location of 6th heating element | front right |
|---|
| Power on indicator | Yes |
|---|
| Plate on indicator | 0 |
|---|
| Type of 3rd heating element | Gas |
|---|
| Product group | Hob |
|---|
| Gross weight (kg) | 83.5 |
|---|
| Number of induction elements | 0 |
|---|
| Number of Double grates | 3 |
|---|
| Alternative gas type | Liquid gas 27,5 mbar (USA) |
|---|
| Knob Material | Full metal |
|---|
| Type of lid | Without |
|---|
| Color of frame | Stainless steel, Stainless Steel |
|---|
| LP Gas Connection Rating | 90000 |
|---|
| Minimum distance from rear wall | 12'' |
|---|
| Depth of the packed product (mm) | 1350 |
|---|
| Number of electric warming zones | 0 |
|---|
| Additional Image 3 | https |
|---|
| Location of 3rd heating element | Hinten links der Mitte |
|---|
| Type of heating element | Gas |
|---|
| Power cord length (cm) | 243.8 |
|---|
| Current (A) | 15 |
|---|
| Number of radiant elements | 0 |
|---|
| Location of control panel | Front |
|---|
| Gross weight | 184.000 |
|---|
| Construction type | Built-in |
|---|
| Volts (V) | 120 |
|---|
| Number of halogen elements | 0 |
|---|
| Type of safety device for gas | Central electronic safety device |
|---|
| Number of electric elements | 0 |
|---|
| Gas type | Natural gas 15 mbar (USA) |
|---|
| UPC code | 825225935537 |
|---|
| Type of frame | Professional, Standard frame |
|---|
| Power of 3rd burner | 15000 |
|---|
| Net weight | 147.000 |
|---|
| EAN code | 825225935537 |
|---|
| Power Cord Length | 96'' |
|---|
| Additional Image 6 | https |
|---|
| Required cutout size (HxWxD) | 10 9/16'' x 46 1/4'' x 7 11/16'' |
|---|
| Number of gas burners | 6 |
|---|
| Number of electric cooking zones | 0 |
|---|
| Type of control | Mechanical |
|---|
| Included accessories | 3 x cast iron pan support, 1 x griddle, 1 x island trim |
|---|
| Type of 4th heating element | Radiant heating |
|---|
| Additional Image 4 | https |
|---|
| Type of 6th heating element | Gas |
|---|
| Power of 2nd burner | 15000 |
|---|
| Energy input | Gas |
|---|
| Additional Image 1 | https |
|---|
| Power of 4th heating element (kW) | 1.63 |
|---|
| Power of 5th burner | 15000 |
|---|
| Additional Image 2 | https |
|---|
| Internal article number | PCG486WD |
|---|
| Main on/off switch | No |
|---|
| Power of 6th burner | 18000 |
|---|
| Power of 1st burner | 18000 |
|---|
| Plug type | 120V-3 prong |
|---|
| Sealed Burners | Yes |
|---|
| Optional accessories | PA12CHPBLK, PA12GRILFW, PA12GRILLW, PA12LCVRW, PA48WLBC, PAALTKITH, PAGRIDDLE, PAKNOBLUWR, PALPKITHW, PWOKRINGHC |
|---|
| Product name / series name | mixed hob w integr controls |
|---|
| Timer | No |
|---|
