| Ignition System | Electronic |
|---|
| Handle Color | Black Stainless |
|---|
| App Filter - Cooking Technology | Convection |
|---|
| App Filter - WiFi Connect | Built-In |
|---|
| Control Location | Front controls |
|---|
| App Filter - Cooktop Type | Standard Grates |
|---|
| App Filter - Cleaning Type | Steam and Self-Clean |
|---|
| App Filter - Fuel Type | Gas |
|---|
| Parts Warranty | Limited 1-year entire appliance |
|---|
| App Filter - Cabinet Width | Cooking 30 in. (Standard) |
|---|
| Color Appearance | Fingerprint Resistant Black Stainless |
|---|
| Height to Cooking Surface (in.) | 36 1/4 +/- 1/4 |
|---|
| App Filter - Product Type | Ranges Slide-In Single Oven |
|---|
| Center Grate | Included |
|---|
| Grill | Included, JXGRILL1 |
|---|
| Oven Control Features | Audible Preheat Signal, Auto Recipe Conversion, Auto Self Clean, Certified Sabbath Mode, Control Lock Capability, Electronic Clock & Kitchen Timer, Front Controls, In-Oven Broiling, Temperature Probe |
|---|
| Cooktop Burner Grate Features | Edge-to-Edge Grates |
|---|
| Self-Clean Oven Door Lock | Automatic |
|---|
| Interior Oven Light | 1 Incandescent |
|---|
| Sabbath Mode | Yes |
|---|
| Oven Cleaning Type | Self-Clean with Steam Clean Option |
|---|
| Depth with Door Open | 47.5 in |
|---|
| Approximate Shipping Weight | 244 lb |
|---|
| Control Type | Glass Touch |
|---|
| Oven Rack Features | 3 Self-Clean Oven Racks |
|---|
| OU Certified | No |
|---|
| Fuel Type | Natural Gas (factory set) |
|---|
| Height to Top of Rear Vent Trim | 37.625 in |
|---|
| Burner - Right Rear | 9,500 BTU |
|---|
| Optional Accessories | WB48X21543 Roller Rack |
|---|
| Top Burner BTU Rating - LP (000's BTU's) | (1) 18.0; (1) 15.0; (2) 9.5; (1) 5.0 |
|---|
| Cabinet Width | 30 in |
|---|
| Griddle | Reversible Integrated Grill/Griddle (Included) |
|---|
| App Filter - Edge-to-Edge Cooktop | Yes |
|---|
| Warranty Notes | See written warranty for full details |
|---|
| Burner - Left Front | 21,000 BTU Tri-ring Burner |
|---|
| Cooking System | True European Convection |
|---|
| Connected Capabilities | Amazon Alexa, DiGiorno, Fresco, IFTTT, Innit, Sonos, The Google Assistant |
|---|
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Bake / 16.5 Broiler |
|---|
| Total Capacity (cubic feet) | 5.6 cu ft |
|---|
| Bake/Broiler BTU Rating - LP (000's BTU's) | 16.0 Bake / 13.5 Broiler |
|---|
| Cooktop Burner Grate Color | Matte Black |
|---|
| Cooktop Burner Grate Material | Heavy Cast Iron |
|---|
| Oven Cooking Modes | Convection Bake, Convection Roast, Frozen Pizza Multi Rack, Frozen Pizza Single Rack (No Preheat), Frozen Snacks Multi Rack, Frozen Snacks Single Rack (No Preheat), No Preheat Air Fry, Proof, Warming |
|---|
| Burner - Center | 9,500 BTU Dual Oval |
|---|
| Cooktop Type | Standard Grates |
|---|
| Air Fry Basket | Optional- JXAFTRAY1VSS |
|---|
| Burner - Right Front | 15,000 BTU |
|---|
| LP Conversion Kit | Included |
|---|
| Oven Door Features | Big View Oven Window |
|---|
| Cabinet Opening | 30 in |
|---|
| Labor Warranty | Limited 1-year entire appliance |
|---|
| Handle | Designer Style |
|---|
| Cooktop Burner Type | Sealed |
|---|
| Oven Interior | 1 Incandescent Light, Black |
|---|
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 21.0 (1) 15.0; (2) 9.5; (1)5.0 |
|---|
| Control Knobs | Black Stainless |
|---|
| WiFi Connect | Built-In |
|---|
| Drawer Type | Storage |
|---|
| App Filter - Tri-Ring Burner | Yes |
|---|
| Product Type | Slide-In Single Oven |
|---|
| Cooking Technology | Convection |
|---|
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19-1/2 x 20-5/8 |
|---|
| Installation | Flush Appearance, Free-standing cut-out |
|---|
| Net Weight | 224 lb |
|---|
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
|---|
| Trim Kit | JXFILLR1DD, Optional |
|---|
| Burner - Left Rear | 5,000 BTU Precise Simmer |
|---|
| Dual Ring Burners | Yes |
|---|
| Configuration | Range with Smooth Glide Storage Drawer |
|---|
| Depth Without Handle | 26.875 in |
|---|
| Cooktop Surface | Deep Recessed, Gray |
|---|
| App Filter - Control Type | Electronic touchpad |
|---|
| Overall Width | 30 in |
|---|
| App Filter - Drawer Type | Storage |
|---|
| Overall Depth | 29.5 in |
|---|
| Overall Height | 36.5 in |
|---|
| App Filter - Convection | Yes |
|---|
