Product Description
Innovation The perfect blend of professional grade cooking with a New Contemporary Design that will fit seamlessly into any Kitchen style Exclusive, patented Star® Burner – most even heating, unsurpassed flame coverage Can be installed with zero inch clearance, flush against rear wall surface. Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners Superfast 2-hour self-clean mode Performance Five burner Range with an overall output of 59,000 BTU (NG) Raised pedestal burner and porcelain maintop for effortless cleaning Electronic re-ignition will automatically re-ignite the burner in case the flame goes out ExtraLow® feature provides a wide range of temperature control, perfect for simmering delicate sauces Powerful, 8-pass bake and broil elements Third Element Convection offers precise airflow for cooking on multiple levels without flavor transfer Massive oven capacity of 4.4 cu.ft. Six rack levels for multiple item cooking One Full Access® telescopic rack and two standard racks, all with integrated easy-grip handle Electronic oven control ensures precise heating Large oven door window for maximum viewing Powerful halogen lighting illuminates the oven cavity Design Bold Professional design Truly Flush Mounted™, 24" standard cabinet depth Patented Pedestal Star® Burner with QuickClean Base™ Professional style, continuous cast iron grates Restaurant style metal knobs 30" units ship standard with island trim included
Features
- Five Star® burners in a convenient 30-inch footprint. The powerful burners fire up 59,000 BTUs yet only require 300 CFM venting
- Two ExtraLow® Burners : These burners offer 5 precise settings that are perfect for simmering meals or melting chocolate without burning.
- One Full Access® Telescopic Rack : glides smoothly on ball bearings, allowing them to extend for safe, easy access while supporting the heaviest dishes.
- True Convection Oven : Convection oven with a third element, adds greater efficiency to your convection baking to cook multiple levels of sheet pans evenly.
- Truly Flush Mounted : designed to fit perfectly flush alongside standard 24" depth cabinets.
Specifications
| Product packaging dimensions (HxWxD) | 49 1/4 x 43 1/2 x 40 3/8 |
|---|
| Required cutout size (HxWxD) | 30'' width slide-in |
|---|
| Power of the heating element | 5.27 |
|---|
| Location of 2nd heating element | center left |
|---|
| Optional accessories - primary cavity | PA12CHPBLK, PA30WLBH, PAALTKITH, PAGRIDDLE, PAKNOBLUWH, PALPKITHW5, PARKB30HY, PWOKRINGHC |
|---|
| Total number of cooktop burners | 5 |
|---|
| Type of heating element | Gas |
|---|
| Additional Image 7 | https |
|---|
| Plate on indicator | 0 |
|---|
| Product color | Stainless steel |
|---|
| Shelves type | Shelf support and telescopic rails |
|---|
| SKU | PRD305WHU |
|---|
| Overall appliance dimensions (HxWxD) | 35 7/8'' x 29 15/16'' x 24 3/4'' |
|---|
| Included accessories | 1 x Broiler pan |
|---|
| Power of 5th heating element (kW) | 2.35 |
|---|
| Timer | No |
|---|
| Height of the packed product (mm) | 1250 |
|---|
| Main on/off switch | No |
|---|
| Additional Image 5 | https |
|---|
| Variable cooker height | 1'' |
|---|
| Type of control | Front;Rotary knob;sword knobs |
|---|
| Location of the heating element | front left |
|---|
| Interior light | Yes |
|---|
| Power on indicator | No |
|---|
| Gross weight | 375.000 |
|---|
| Power of 5th burner | 8000 |
|---|
| Location of 3rd heating element | back left |
|---|
| Number of halogen elements | 0 |
|---|
| Settings backup | No |
|---|
| Product group | Cooker |
|---|
| Knob Material | Full metal |
|---|
| Type of lid | Without |
|---|
| AHAM usable cavity size | 3 |
|---|
| Current (A) | 30 |
|---|
| Frequency (Hz) | 60 |
|---|
| Residual heat indicator | Without |
|---|
| Number of induction elements | 0 |
|---|
| Maximum adjustability feet (mm) | 25 |
|---|
| Trays | 0 |
|---|
| Convection Element Wattages primary cavity | 2750 |
|---|
| Depth with open door 90 degree (mm) | 1140 |
|---|
| Ignition system | Yes |
|---|
| Power of 3rd burner | 8000 |
|---|
| Gross weight (kg) | 170.0 |
|---|
| Product name / series name | Freestand combination cooker |
|---|
| Control panel information | On control knob, On the controls, Printing on panel front, Printing on panel front |
|---|
| Type of 3rd heating element | Gas |
|---|
| Power of 6th burner | 15000 |
|---|
| Sealed Burners | No |
|---|
| Adjustable feet | Yes - all |
|---|
| Additional Image 1 | https |
|---|
| Bake Element Wattages primary cavity | 2000 |
|---|
| Door Material - primary cavity | Stainless steel |
|---|
| Construction type | Freestanding |
|---|
| Additional Image 6 | https |
|---|
| Net weight | 293.000 |
|---|
| Gas connection rating (W) | 17300 |
|---|
| Total BTU load | 59000 |
|---|
| Number of Double grates | 2 |
|---|
| Additional Image 4 | https |
|---|
| Width of the packed product (mm) | 1110 |
|---|
| Brand | Thermador |
|---|
| Safety device | Door Lock Mechanical |
|---|
| Number of electric elements | 0 |
|---|
| Power of 3rd heating element (kW) | 4.4 |
|---|
| Number of interior lights | 2 |
|---|
| Internal article number | PRD305WHU |
|---|
| Position of interior lights | left side, right side |
|---|
| Additional Image 3 | https |
|---|
| Type of control | Electronic |
|---|
| Optional accessories | PA12CHPBLK, PA30WLBH, PAALTKITH, PAGRIDDLE, PALPKITHW5, PARKB30HY, PWOKRINGHC |
|---|
| Depth of the packed product (mm) | 1026 |
|---|
| Type of 5th heating element | Gas |
|---|
| Additional Image 2 | https |
|---|
| Plug type | No Plug |
|---|
| Alternative gas type | Liquid gas 27,5 mbar (USA) |
|---|
| UPC code | 825225925248 |
|---|
| Location of 6th heating element | center right |
|---|
| Number of gas burners | 5 |
|---|
| Number of cavities (2010/30/EC) | 1 |
|---|
| Power of 6th burner | 10000 |
|---|
| Motorized turn spit | No |
|---|
| Number of radiant elements | 0 |
|---|
| Which kind of hobs can be controlled? | Gas |
|---|
| Volts (V) | 240/208 |
|---|
| Probe | No |
|---|
| Number of electric cooking zones | 0 |
|---|
| Grids | 0 |
|---|
| Location of 5th heating element | back right |
|---|
| EAN code | 825225925248 |
|---|
| Net weight (kg) | 133.0 |
|---|
| Location of 4th heating element | middle back |
|---|
| Type of safety device for gas | Electromagnetic for each burner |
|---|
| Power of 1st burner | 18000 |
|---|
| Material Color - door | Stainless Steel |
|---|
| Automatic programmes | No |
|---|
