Product Description
Innovation Cooktop Hood Sync allows hood control on Freedom® cooktop touchscreen Cooktop Hood Sync enables hood activation once Freedom® cooktop is on Remotely monitor, control, and start through the Home Connect app Flexibility to program custom settings the through Home Connect app Manage Thermador Connected Experience kitchen suite with one network Access tips and tricks on Home Connect app to master every aspect Opt to receive mobile notifications as a reminder to clean filters Performance Suitable for wall or island applications Select the precise fan speed needed with four different settings Built-in 'Clean Filter' reminder light illuminates after 40 hours of operation Delayed shut off tackles lingering odors for up to 10 minutes Filter systems are highly efficient at capturing grease Perimetric design allows for efficient capture of smoke and steam Powerfully Quiet® ventilation systems Design Beautiful illumination with white multiple level LED lighting Recessed control set at an angle for easy view-ability and completely flush design Built-in remote control panel accessory available, sold separate
Features
- Masterpiece® Wall Hoods add bold, distinct flair to your kitchen and are crafted to complete the ultimate cooking system
- Wi-Fi Enabled : allows for remote monitoring and control of lights and fan speed, notification to clean the grease filter via Home Connect app, works with smart home devices and services like Amazon Alexa.
- Delay Shut Off & Automatic Mode : features an Automatic Mode, that adjusts the fan speed according to your cooking style, as well as Delay Shut Off, which runs the hood 10 minutes after you are done cooking to remove any lingering odors.
- LED Lighting : highlights your meal from first course to last with multi-level vivid LED Lighting.
- Sleek Electronic Touch Control Panel : convenient control that is easy-to-use and easy-to-clean.
Specifications
| Light Control Type | Continuous |
|---|
| Power Cord Length | 51 1/8" |
|---|
| Number of motors | 1 |
|---|
| Height of product, without chimney (mm) | 267 |
|---|
| Height of the packed product (mm) | 394 |
|---|
| Product packaging dimensions (HxWxD) | 15 1/2'' x 37 1/4'' x 13'' |
|---|
| Type of manual control devices | touch control |
|---|
| Additional Image 2 | https |
|---|
| Diameter of air duct top | 6 |
|---|
| Minimum width for installation (mm) | 812 |
|---|
| Volts (V) | 120 |
|---|
| Frequency (Hz) | 60 |
|---|
| Typology | Built-in/Built-under |
|---|
| Additional Image 1 | https |
|---|
| Width of the packed product (mm) | 330 |
|---|
| Installation type | Wall-mounted |
|---|
| Design | Integrated hood |
|---|
| Number of speed settings | 4-stage |
|---|
| Product group | Hood |
|---|
| Additional Image 3 | https |
|---|
| Overall appliance dimensions (HxWxD) | 5 3/4'' x 32 1/2'' x 10 5/8'' |
|---|
| Brand | Thermador |
|---|
| Motor location | Integrated motor in hood body |
|---|
| Odour filter | No |
|---|
| Internal article number | VCI3B36ZS |
|---|
| Gross weight (kg) | 14.2 |
|---|
| Type of control | LED;Touch Control |
|---|
| EAN code | 825225961277 |
|---|
| Optional accessories | CHFVCI36ZS, REMCPW |
|---|
| Watts (W) | 159 |
|---|
| Type of automatic control devices | Control via cooker/hotplate |
|---|
| Type of control | Electronic |
|---|
| Depth for installation (mm) | 260 |
|---|
| Diameter of air duct (mm) | 150 |
|---|
| Construction type | Built-in |
|---|
| SKU | VCI3B36ZS |
|---|
| Air exhaust | Yes |
|---|
| Required distance above cooktop/ranges | 30''/30'' |
|---|
| Color body | Stainless Steel |
|---|
| Maximum width for installation (mm) | 812 |
|---|
| UPC code | 825225961277 |
|---|
| Net weight (kg) | 12.1 |
|---|
| Discharge direction | vertical |
|---|
| Gross weight | 31.000 |
|---|
| Additional Image 5 | https |
|---|
| No-return airflow flap | No |
|---|
| Type of lamps used | Low consumption |
|---|
| Maximum height for installation (mm) | 584 |
|---|
| Number of lights | 2 |
|---|
| Remote control | Yes |
|---|
| Plug type | No Plug |
|---|
| Additional Image 4 | https |
|---|
| Total power of the lamps (W) | 40 |
|---|
| Depth of the packed product (mm) | 946 |
|---|
| Minimum height for installation (mm) | 381 |
|---|
| Clean filter reminders | Yes |
|---|
| Total output power of the motors | 150 |
|---|
| Net weight | 27.000 |
|---|
| Power cord length (cm) | 150.0 |
|---|
| Total luminance (lux) | 150 |
|---|
